WL Tandem

Parlok WL Tandem mudguards are available in two widths 430 mm and 650 mm and in a wide range of various lengths. You can also build it up from the straight and curved parts. The strengthening hollows ensure even a long mudguard staying in shape and give support to the construction. Available also with integrated spray-suppression.

WL Tandem Supra



Tridem parts and assembly

Parlok White Line™ Tandem mudguards can be delivered also in parts, which saves space in transportation. This way you can use the straight and curved parts and build up the mudguard by yourself. The curved part is available also including Supra spray-suppression. This whole combination is referred to as Tridem.

Item No.	B	L	R	S	H	F
102690	430	2070*	650	1650	705
102682	430	1000		1000
102688	430	1380		1380
103217	430	1450	650		1080	400

*Length without the joint piece of the straight part.

Item No.	B	L	R	S	H	F
102726	650	2050*	630	1630	695
102724	650	1000		1000
102725	650	1420		1420
102761	650	1450	630		1095	400



In the above table you can find the measurements of the Tridem mudguard delivered in parts.

In addition you need:
100359 Installation kit for 430 Mudguard straight including 6 pcs M6 screws, nuts and washers**
100360 Installation kit for 650 Mudguard straight including 8 pcs M6 screws, nuts and washers**
**1 x installation kit required per mudguard.



In the below table you can find the measurements of the assembled Tandem mudguard:
